R5104-59 Spring Toggle Latch, Nickel Plated, Panel Fastener

The NRH R5104-59 is a heavy-duty toggle latch designed for applications requiring a stronger, secure closure. Constructed from SPCC steel with a durable Nickel Plating finish, it offers a cost-effective yet robust solution. The latch features a spring mechanism that provides smooth and consistent operation during manual engagement and disengagement, enhancing usability. With a substantial tensile load capacity of 245N (25kg), it is built to handle more demanding fastening tasks.

Technical Specifications (Based on Provided Product Image)

Item	Specification / Description
Brand	NRH (Na Hui Box Hardware)
Model Number	R5104-59
Product Name	Toggle Latch
Material	SPCC (Steel)
Finish	Nickel Plating
Net Weight	19g
Tensile Load	245N (25kg)
Key Dimensions (from drawing)	Overall Length: 44mm Overall Width: 27mm Overall Height: 20mm Mounting Holes: 4 x Ø4.2mm
Note	Detailed dimensioned drawings are provided in the image for integration reference.

Product Overview: Robust Latching for Heavy-Duty Use

The NRH R5104-59 is engineered for strength and reliability. It operates via a manual over-center toggle mechanism, where the user presses the latch down to lock and lifts it to unlock. The integrated spring ensures the action is smooth and provides positive tactile feedback. The use of SPCC steel provides the core strength, while the Nickel Plating offers a layer of corrosion resistance and a uniform, clean appearance. Its design is compact yet robust, making it suitable for applications where a higher clamping force is required.

Core Features

Higher Tensile Load Capacity: With a 245N (25kg) tensile load rating, this latch provides a stronger holding force suitable for heavier panels or more demanding environments.
Smooth Spring-Assisted Operation: The built-in spring delivers a consistent and quality feel during the locking and unlocking cycle.
Durable Nickel-Plated Finish: The nickel plating on the SPCC steel base provides good corrosion resistance and a clean, professional look.
Heavy-Duty Construction: The overall design and material choice are geared towards applications that require a more robust fastening solution than standard latches.

Ideal Applications

Given its higher load rating and sturdy construction, the R5104-59 is well-suited for:

Industrial Toolboxes & Chests: Providing a secure closure for heavy-duty tool storage.
Machine Guarding & Safety Doors: Securing access panels on industrial equipment where a positive lock is critical.
Heavier Equipment Cases & Transit Containers: For locking lids on cases containing heavier instruments or components.
Agricultural & Construction Equipment Panels: Fastening access hatches and covers in rugged environments.

Choose a robust latch for demanding applications. The NRH R5104-59 Spring Toggle Latch offers increased strength and reliable, smooth operation for your heavy-duty fastening needs.
