The NRH 5102-88K is a robust and reliable toggle latch designed to securely fasten two separate panels or doors together. Crafted from SPCC steel and finished with a durable chrome plating, it fe……

Send Inquiry

Functional characteristics

NRH 5102-88 Toggle Latch | SUS304 Stainless Steel Spring Latch for Enclosures

The NRH 5102-88K is a robust and reliable toggle latch designed to securely fasten two separate panels or doors together. Crafted from SPCC steel and finished with a durable chrome plating, it features a spring-assisted mechanism for smooth operation and positive locking. Stamped with the “NRH” logo, this product represents the quality of a manufacturer with expertise since 1996. It is certified to major international standards including ISO 9001:2000 and complies with REACH, ROHS, and SVHC, making it a dependable choice for demanding applications.

Primary Applications:

This versatile latch is engineered to join and secure two surfaces across a wide range of demanding industries:

Military & Defense: Field equipment cases, weapon storage containers, ruggedized communication boxes, and transport cases.
Aerospace & Aviation: Flight cases for sensitive instruments, ground support equipment housings, and aircraft accessory panels.
Industrial Machinery & Enclosures: Access panels on CNC machines, electrical control cabinet doors, welding machine covers, and machinery guards.
Instrumentation & Measurement: Test and measurement equipment cases, calibration device housings, and portable analyzer boxes.
Medical & Laboratory Equipment: Sterilization container lids, mobile cart drawers, and secure covers for sensitive instruments.
Transportation & Logistics: Truck toolbox doors, shipping container access points, and protective cases for high-value cargo.
Telecommunications & Outdoor: Hinged doors on outdoor cabinets, network shelter panels, and field-deployable equipment cases.

How It Works (Operating Principle):

This latch functions as a spring-assisted toggle mechanism specifically designed to clamp two objects together. The base plate is mounted on one surface, while the pivoting lever with its hook engages a strike plate mounted on the opposing surface. When the lever is pressed down, the spring-loaded action takes up slack, and the over-center toggle mechanism pulls the two surfaces tightly together, creating a secure, rattle-free joint. Lifting the lever releases the tension, allowing the surfaces to separate.

Features & Specifications:

Durable Construction: Made from SPCC steel for reliable strength and formability in industrial settings.
Corrosion-Resistant Finish: Chrome plating provides a bright, protective surface that resists rust and wear.
Spring-Assisted Clamping: The integrated spring ensures smooth operation and helps maintain consistent tension, pulling the two fastened objects firmly together.
Optimized Strength-to-Weight: With a net weight of only 61g, it offers a substantial 294N (30kg) tensile load capacity for secure fastening.
Precision Design for Secure Fit: Detailed engineering drawings (Overall Length: 88mm, Mounting Holes: 4xΦ5.2mm) ensure precise installation and alignment for a tight seal between the two joined parts.
Trusted Brand & Compliance: Features the “NRH” stamp. Certified to ISO 9001:2000 quality standards and compliant with SGS, REACH, ROHS, and SVHC.

Technical Specifications:

Item	Specification
Brand	NRH Box Hardware
Model Number	5102-88K
Product Name	Toggle Latch
Primary Material	SPCC Steel
Surface Finish	Chrome Plating
Product Weight	61g
Tensile Load	294N (30kg)
Key Dimensions	Overall Length: 88mm, Width: 25mm, Height: 34mm, Mounting Holes: 4 x Φ5.2mm. Refer to the provided technical drawing for all detailed dimensions.
Compliance	ISO 9001:2000, SGS, REACH, ROHS, SVHC
Additional Info	Manufacturer Since 1996. OEM/ODM Services Available.
