NRH 4201-110-1 Spring Handle | Chrome Plated SPCC Handle without Grip

NRH 4201-110-1 Spring Handle - SPCC Steel, Chrome Plating, No Rubber Grip, 30kg Load, 90° Stop

The NRH 4201-110-1 is a cost‑effective and functional spring handle designed for applications where a reliable carrying solution is needed without a rubberized grip. Constructed from durable SPCC steel with a bright chrome plating finish, it provides essential functionality with a clean, all‑metal aesthetic. This model features the same reliable spring mechanism with a 90‑degree stop for stable lifting and automatic return action as other NRH handles, but is offered without a rubber or plastic grip overlay. With a net weight of 134g and a higher 294N (30kg) tensile load capacity, it is a robust choice for general industrial use.

Key dimensions include an overall length of 96mm, overall width of 71.5mm, bail width of 30mm, and mounting plate size of 61mm x 96mm, with 4x Ø5.5mm mounting holes. Additional drawing dimensions: 110mm, 84mm, 61mm, 2.2mm.

Primary Applications

• Industrial equipment and consoles: Handles for control cabinets, server racks, electrical enclosures, and machinery housings where a metal finish is preferred
• Tool storage and workstations: Toolboxes, mobile carts, and workshop furniture that require a durable, easy‑to‑clean handle
• Transportation cases: Flight cases, shipping containers, and composite boxes for equipment that does not require a cushioned grip
• Utility and outdoor enclosures: Generator covers, utility boxes, and outdoor equipment cases where environmental resistance is provided by the chrome plating

How It Works - Operation Principle

The handle operates on a straightforward spring mechanism. To use, pull the metal U‑shaped bail upwards; it will extend until it reaches the integrated 90‑degree stop, providing a stable position for carrying. To store, simply release the handle. The internal spring will automatically retract it, allowing the bail to fold down completely flat against the mounting plate. This offers a space‑saving, low‑profile design.

Features & Specifications

• Pure metal construction: Made from SPCC steel with a chrome plating finish, offering a clean, industrial look without any rubber or plastic overlays
• 90‑degree carrying stop: Provides a stable, fixed position for safe and easy lifting
• Automatic spring return: Retracts and folds flat automatically when released, maximizing space efficiency
• Higher load capacity: Rated for a tensile load of 294N (30kg), suitable for heavier applications
• Precise dimensions: Engineered for easy installation with overall length 96mm, width 71.5mm, and 4x Ø5.5mm mounting holes on a 61mm x 96mm pattern

Technical Specifications

• Brand: NRH Box Hardware
• Model Number: 4201-110-1
• Product Name: Spring Handle (No Grip)
• Primary Material: SPCC Steel
• Surface Finish: Chrome Plating
• Grip: None (Bare Metal)
• Product Weight: 134g
• Tensile Load: 294N (30kg)
• Key Dimensions: Overall Length: 96mm, Overall Width: 71.5mm, Bail Width: 30mm, Mounting Plate: 61mm x 96mm, Mounting Holes: 4 x Ø5.5mm
• Additional Details: Other dimensions as per drawing: 110, 84, 61, 2.2

Why Trust NRH

NRH Box Hardware has been producing industrial spring handles for decades. The NRH 4201-110-1 is made under a certified quality management system. Our long‑standing expertise in steel handles ensures a reliable, cost‑effective solution for industrial equipment, tool storage, and transportation cases where a bare metal grip is preferred.
