NRH 4101-132 Stainless Gloss Spring Flush Pull – SUS304 60kg Auto Retracts

NRH 4101-132 Stainless Steel Gloss Spring Flush Pull - SUS304 Mirror, 60krmaceutical environments, a handsle must not only be strong - it must be cleanable. The NRH 4101-132 is manufactured from SUS304 stainless steel with a mirror gloss finish (Ra ≤ 0.4μm). Bacteria and dirt have nowhere to hide, and disinfectant wipes glide effortlessly over the surface. An internal stainless steel spring automatically retracts the handle flush with the panel when released - no protrusions, no snags, no hidden crevices. Rated at 60kg pull load yet weighing only 215g, it handles hospital carts, pharmaceutical equipment doors, and food processing panels with ease. The mirror finish not only looks premium but also reflects light, making equipment stand out in cleanrooms.

Produced under ISO 9001, with 50,000‑cycle spring testing. REACH, RoHS, SVHC compliance available on request. OEM/ODM options: brushed finish, modified hole patterns, custom spring tension. 2D/3D CAD drawings supplied.

Critical cut‑out dimensions (see drawing): overall length ~132.5mm, body width ~74.5mm, 4 mounting holes. Reference locating dimensions: 117mm, 104.1mm, 100mm, 80.5mm, 69mm, 58mm, 115mm. Follow drawing precisely.

Mirror Stainless Steel + Auto Retract = Hygiene Champion

Conventional handles have gaps and recesses where contaminants accumulate. A mirror‑finished stainless steel surface has virtually no pores - wipe it once, it's clean. The spring‑loaded flush design eliminates the need to manually push the handle back, removing another potential dirt trap. For medical devices, laboratory instruments, and food production lines, this combination is the preferred solution under GMP and FDA guidelines.

Applications - Where Cleanliness Is Non‑Negotiable

• Medical carts / hospital beds - mirror finish easy to disinfect, spring retraction prevents patient injury
• Pharmaceutical equipment control cabinets - meets GMP no‑dead‑corner requirements
• Food processing machinery doors - resists acidic cleaners, gloss surface repels oil
• Laboratory biosafety cabinets - smooth surface doesn't trap microbes, alcohol‑wipe friendly
• Marine instrument enclosures - SUS304 resists salt spray, gloss sheds salt crystals
• Operating room equipment panels - low‑glare mirror finish, seamless integration
• Semiconductor cleanroom equipment - low particle emission, easy to clean

How It Works - Simple Spring, Superior Reliability

Inside the handle is a single stainless steel compression spring. Normally, the spring holds the grip recessed flush with the panel. To use, hook your fingers (even gloved) and pull - the grip extends smoothly. Release, and the spring instantly returns it flush. No complex cams, no plastic parts to fail. Installation requires cutting a matching hole and securing the base with four screws from the rear. Zero maintenance.

Key Advantages - Beyond Aesthetics

• 60kg actual load capacity - tested, not just claimed
• Solid SUS304 construction - no plating to peel, rust‑proof through and through
• Mirror surface Ra ≤0.4μm - 50% faster cleaning, bacteria cannot adhere
• 50,000‑cycle spring - 6.8 years of daily use (20 cycles/day)
• -20°C low‑temperature operation - works in cold storage and northern outdoor sites
• Brushed finish option - available for anti‑glare requirements
• Generous tolerance - cut‑out ±0.5mm still works

Technical Specifications

• Brand/Model: NRH 4101-132
• Material: SUS304 Stainless Steel
• Finish: Mirror Gloss
• Weight: 215g
• Rated Pull Load: 60kg
• Spring: Stainless steel compression, auto retract
• Mounting: Flush, 4‑hole rear screw fixing
• Approx. Dimensions: Length 132.5mm × Width 74.5mm
• Compliance: ISO 9001 / REACH / RoHS / SVHC (on request)
• Note: Drawings for reference. NRH manufacturing since 1996. OEM/ODM welcome.

Why Hygienic Industries Trust NRH Stainless Handles

NRH's stainless flush pulls go beyond material certification - we control surface finish consistency and spring performance batch by batch. The 4101-132 gloss version has passed third‑party tests for surface roughness and corrosion resistance, outperforming industry norms. It is a specified component for several major hospital equipment and pharmaceutical machinery manufacturers. If you need a high‑load, flush‑mount, mirror‑finished spring handle for clean environments, this is the proven choice.
