NRH R4101-132 Chrome Spring Flush Pull – 60kg Carbon Steel Rounded Corners

NRH R4101-132 Chrome Spring Flush Pull - Carbon Steel, 60kg Load, Compact Rounded Corners, Auto Retract

For control cabinets, instrument panels, and small toolboxes where space is tight, handle size and safety matter. The NRH R4101-132 features a compact design with R13.5 rounded corners - eliminating sharp edges that could cut cables or injure operators. Made from carbon steel with a bright chrome plating, it handles 60kg pull load while weighing just 211g. The internal spring automatically retracts the handle flush with the panel when released - no protrusions, no snags. Ideal for distribution boxes, laboratory instruments, telecom cabinets, vehicle drawers, and medical carts where space and safety are priorities. NRH quality since 1996 ensures reliable performance.

Produced under ISO 9001. REACH, RoHS available on request. OEM/ODM modifications (hole pattern, spring tension) welcome. 2D/3D CAD drawings supplied.

Key cut‑out dimensions (see drawing): overall length 132.5mm, width 60mm, R13.5 radius, 4 mounting holes. Reference dimensions: 117mm, 104mm, 100mm, 72mm, 7.5mm. Follow drawing precisely, especially the rounded corners.

Rounded Corners: More Than Just Good Looks

Sharp edges on handles can damage wire harnesses and injure hands. The R4101-132 features R13.5 rounded corners that eliminate stress risers, protect cables, and provide a more comfortable grip. The smooth contour also makes cleaning easier - no crevices for dirt to hide.

Applications - Perfect for Tight Spaces

• Small distribution boxes / lighting control panels - compact size saves panel space
• Laboratory analytical instrument enclosures - rounded appearance enhances device quality
• Telecom cabinets / base station equipment - auto retract prevents snagging patch cords
• Vehicle toolboxes / RV drawers - lightweight, spring retraction prevents rattling
• Medical cart drawers - rounded corners avoid scratching staff, chrome easy to disinfect
• Vending machine service doors - high cycle life, rounded corners prevent impact injuries

How It Works - Standard Spring, Reliable Retraction

Compression spring holds grip recessed. Pull to extend; release, and spring returns it flush. Rounded corners do not affect mechanical function but improve safety and ergonomics.

Key Advantages

• 60kg rated load - suitable for most industrial doors and drawers
• Compact size (132.5mm) - saves panel space, ideal for small equipment
• R13.5 rounded corners - protects cables, comfortable grip, easy to clean
• Carbon steel + chrome plating - strength, corrosion resistance, bright finish
• Auto retract - prevents snags, saves space
• Lightweight (211g) - reduces overall equipment weight
• OEM flexible - spring force, hole pattern customizable

Technical Specifications

• Brand/Model: NRH R4101-132
• Material: Carbon Steel
• Finish: Chrome Plating
• Weight: 211g
• Rated Pull Load: 60kg
• Spring: Compression, auto retract
• Mounting: Flush, 4‑hole rear screw fixing
• Approx. Dimensions: Overall length 132.5mm, width 60mm, corner radius R13.5
• Compliance: ISO 9001 / REACH / RoHS (on request)
• Note: Drawings for reference. NRH manufacturing since 1996. OEM/ODM welcome.

Why Compact Equipment Chooses NRH Rounded Spring Pulls

The R4101-132 combines 60kg load capacity, auto retract, and a space‑saving rounded design. It has become a standard for precision instruments, telecom equipment, and vehicle drawers where both safety and compactness matter. If you need a flush‑mount, spring‑loaded handle that saves space and protects cables, this is the proven choice.
