NRH 4403-163 ABS Swivel Carry Handle – 35kg Black for Briefcases & Cases

NRH 4403-163 ABS Swivel Carry Handle - Black, Foldable, 35kg Load, for Briefcases & Carrying Cases

Whether it's a business briefcase, carry‑on suitcase, precision instrument case, or professional flight case, the carrying handle defines the user experience. The NRH 4403-163 is a swivel carry handle specifically engineered for briefcases and portable cases. Molded from high‑strength ABS engineering plastic with a matte black finish, it resists impact, wear, and offers a comfortable grip. The handle rotates 180° - lying flat when not in use to save space and allow stacking, and flipping up when needed for carrying. Rated for 35kg load at just 102g, it's lightweight yet strong. Four standard mounting holes (4×Φ3.2mm) fit common case cutouts. Perfect for briefcases, instrument cases, flight cases, medical kits, and photography cases.

Manufactured under ISO 9001. REACH, RoHS compliance available on request. OEM/ODM modifications (color, logo) welcome. 2D/3D CAD drawings supplied.

Key dimensions (see drawing): overall length 161mm, mounting distance 87mm, 4×Φ3.2mm mounting holes, body width 43mm, thickness 20.4mm. Follow drawing for precise cutout.

Swivel Design: Optimized for Briefcases & Cases

Fixed handles always protrude, wasting space and creating snag points - a problem for stacked flight cases or crowded luggage. This handle lies flat when not in use, allowing cases to be stacked neatly. When you need to carry, simply flip it up - there is no mechanical lock; the handle stays in position by your grip. The pivot uses metal bushings, tested for thousands of cycles - smooth, no sticking.

Applications - Specifically for Briefcases & Carrying Cases

• Business briefcases / document cases - comfortable grip for daily commute, sleek appearance
• Carry‑on suitcases / cabin luggage - auxiliary handle for lifting over curbs or into overhead bins
• Precision instrument cases - lightweight, 35kg capacity, protects delicate equipment
• Professional flight cases / ATA road cases - folds flat for stacking, prevents crushing
• Medical first aid kits / field medical cases - quick lift, easy to carry
• Photography equipment cases / lens cases - durable, comfortable to carry
• Sample display cases / presentation cases - frequent handling, durable and attractive

How It Works - Simple Pivot, No Complex Locking

Integrated metal bushings at each end connect the handle to the base. The handle rotates approximately 180°. When not in use, it lies flat against the case. To carry, flip it up - the handle stays in the raised position while you grip it, but there is no latch or lock; it relies on your hand to maintain the angle. This simple design means fewer failure points. The base mounts with four countersunk screws - no exposed hardware.

Key Advantages

• 35kg rated load - sufficient for most briefcases and instrument cases
• ABS engineering plastic - high strength, impact resistant, lightweight
• 180° swivel, folds flat - stacks neatly, no protrusions
• Matte black finish - scratch‑resistant, non‑reflective, hides dirt
• Standard mounting holes - 4×Φ3.2mm, fits common case patterns
• Ultra‑lightweight (102g) - adds minimal travel weight
• OEM ready - custom colors, logo printing available

Technical Specifications

• Brand/Model: NRH 4403-163
• Material: ABS Engineering Plastic
• Finish: Matte Black
• Weight: 102g
• Load Capacity: 35kg
• Swivel Angle: Approx. 180° (flat ↔ flipped up)
• Mounting: 4×Φ3.2mm countersunk holes
• Approx. Dimensions: Overall length 161mm, mounting distance 87mm, width 43mm, thickness 20.4mm
• Compliance: ISO 9001 / REACH / RoHS (on request)
• Note: Drawings for reference. NRH manufacturing since 1996. OEM/ODM welcome.

Why Briefcase & Case Makers Trust NRH Swivel Handles

The NRH 4403-163 is widely used on aluminum briefcases, ABS suitcases, professional flight cases, and medical kits. Its impact‑resistant ABS, smooth swivel action, and practical load rating make it the go‑to choice for portable cases. If you need a rugged, foldable carry handle for your briefcases or carrying cases, this is the proven solution.
