NRH 5102-88K Heavy Duty Toggle Latch | SPCC Steel Spring Latch for Industrial Cases
Made to Order
The NRH 5102-88K is a robust and reliable toggle latch designed to securely fasten two separate panels or doors together. Crafted from SPCC steel and finished with a durable chrome plating, it features a spring-assisted mechanism for smooth operation and positive locking. Stamped with the “NRH” logo, this product represents the quality of a manufacturer with expertise since 1996. It is certified to major international standards including ISO 9001:2000 and complies with REACH, ROHS, and SVHC, making it a dependable choice for demanding applications.
Primary Applications:
This versatile latch is engineered to join and secure two surfaces across a wide range of demanding industries:
-
Military & Defense: Field equipment cases, weapon storage containers, ruggedized communication boxes, and transport cases.
-
Aerospace & Aviation: Flight cases for sensitive instruments, ground support equipment housings, and aircraft accessory panels.
-
Industrial Machinery & Enclosures: Access panels on CNC machines, electrical control cabinet doors, welding machine covers, and machinery guards.
-
Instrumentation & Measurement: Test and measurement equipment cases, calibration device housings, and portable analyzer boxes.
-
Medical & Laboratory Equipment: Sterilization container lids, mobile cart drawers, and secure covers for sensitive instruments.
-
Transportation & Logistics: Truck toolbox doors, shipping container access points, and protective cases for high-value cargo.
-
Telecommunications & Outdoor: Hinged doors on outdoor cabinets, network shelter panels, and field-deployable equipment cases.
How It Works (Operating Principle):
This latch functions as a spring-assisted toggle mechanism specifically designed to clamp two objects together. The base plate is mounted on one surface, while the pivoting lever with its hook engages a strike plate mounted on the opposing surface. When the lever is pressed down, the spring-loaded action takes up slack, and the over-center toggle mechanism pulls the two surfaces tightly together, creating a secure, rattle-free joint. Lifting the lever releases the tension, allowing the surfaces to separate.
Features & Specifications:
-
Durable Construction: Made from SPCC steel for reliable strength and formability in industrial settings.
-
Corrosion-Resistant Finish: Chrome plating provides a bright, protective surface that resists rust and wear.
-
Spring-Assisted Clamping: The integrated spring ensures smooth operation and helps maintain consistent tension, pulling the two fastened objects firmly together.
-
Optimized Strength-to-Weight: With a net weight of only 61g, it offers a substantial 294N (30kg) tensile load capacity for secure fastening.
-
Precision Design for Secure Fit: Detailed engineering drawings (Overall Length: 88mm, Mounting Holes: 4xΦ5.2mm) ensure precise installation and alignment for a tight seal between the two joined parts.
-
Trusted Brand & Compliance: Features the “NRH” stamp. Certified to ISO 9001:2000 quality standards and compliant with SGS, REACH, ROHS, and SVHC.
Technical Specifications:
|
Item
|
Specification
|
|---|---|
|
Brand
|
NRH Box Hardware
|
|
Model Number
|
5102-88K
|
|
Product Name
|
Toggle Latch
|
|
Primary Material
|
SPCC Steel
|
|
Surface Finish
|
Chrome Plating
|
|
Product Weight
|
61g
|
|
Tensile Load
|
294N (30kg)
|
|
Key Dimensions
|
Overall Length: 88mm, Width: 25mm, Height: 34mm, Mounting Holes: 4 x Φ5.2mm. Refer to the provided technical drawing for all detailed dimensions.
|
|
Compliance
|
ISO 9001:2000, SGS, REACH, ROHS, SVHC
|
|
Additional Info
|
Manufacturer Since 1996. OEM/ODM Services Available.
|
| Brand | NRH |
|---|---|
| Country of Origin | China |
| Certifications | CE, ISO9001, UL, SGS, RoHS |
| Minimum Order Quantity | 1 |
| Production Lead Time | 7-30 days |
| Stock Status | Made to Order |
