NRH
R5103-75 Heavy Duty Toggle Latch, Panel Fastener, Cabinet Lock
Made to Order
The NRH R5103-75 is a heavy-duty toggle latch engineered for applications demanding superior strength and reliable closure. As detailed in the product specification sheet, it is constructed from SPCC steel and protected with a Nickel Plating finish. This latch is built to handle significant stress, with a substantial net weight of 31g and an impressive tensile load capacity of 245N (25kg). Its robust design and precise engineering, detailed in the accompanying multi-view drawings, make it a dependable choice for securing heavy doors, panels, and equipment covers.
Technical Specifications (Based on Provided Product Drawing)
|
Item
|
Specification / Description
|
|---|---|
|
Brand
|
NRH Box Hardware
|
|
Model Number
|
R5103-75
|
|
Product Name
|
Toggle Latch
|
|
Material
|
SPCC (Steel)
|
|
Finish
|
Nickel Plating
|
|
Net Weight
|
31g
|
|
Tensile Load
|
245N (25kg)
|
|
Key Dimensions (from drawing)
|
Overall Height: 76mm
Top Plate Width: 31mm Mounting Bracket Height: 19.5mm Latch Body Width: 34.5mm Hook Section Height: 55mm Mounting Holes: 4 x Ø4.2mm Strike Pin Hole: Φ4mm |
|
Note
|
Detailed engineering drawings provided for integration.
|
Product Overview: High-Strength Fastening Solution
The NRH R5103-75 is designed for performance where standard latches may be insufficient. It operates on a reliable over-center toggle mechanism: the user presses the latch arm down to engage the hook with a fixed pin (Φ4mm), creating a powerful, positive lock. The Nickel Plating on the SPCC steel base provides effective corrosion resistance and a durable, clean finish suitable for industrial environments. With a load rating significantly higher than many comparable models, it is the ideal solution for heavier panels and doors that require a secure, vibration-resistant hold.
Core Features
-
High Load Capacity: A 245N (25kg) tensile load rating confirms its suitability for heavy-duty applications, providing a secure closure where greater force is required.
-
Robust & Protective Construction: The combination of SPCC steel and Nickel Plating offers a cost-effective balance of high strength and good corrosion resistance for long-term durability.
-
Precision Engineered Design: Comprehensive technical drawings with exact dimensions (e.g., 76mm height, 4x Ø4.2mm mounting holes) ensure predictable performance and easy integration into product designs.
-
Secure Over-Center Locking: The mechanism delivers a reliable, snap-in lock that resists accidental opening from vibration or impact.
Ideal Applications
Given its high strength rating and sturdy build, the R5103-75 is particularly well-suited for demanding industrial and commercial applications:
-
Heavy-Duty Industrial Cabinets: Securing large doors on electrical switchgear enclosures, server racks, and large control panels.
-
Machinery Guards & Safety Covers: Fastening robust protective covers and access hatches on industrial machinery and equipment.
-
Transport Cases for Heavy Equipment: Providing a secure closure for large tool chests, generator cases, and equipment transit containers.
-
Outdoor & Utility Enclosures: Locking access points on robust communication cabinets, power distribution boxes, and other field-deployed equipment.
Engineered for strength, built for reliability. The NRH R5103-75 Toggle Latch delivers the high-load performance needed for your most demanding fastening challenges.
| Brand | NRH |
|---|---|
| Country of Origin | China |
| Certifications | CE, ISO9001, UL, SGS, RoHS |
| Minimum Order Quantity | 1 |
| Production Lead Time | 7-30 days |
| Stock Status | Made to Order |
