R5151-33 Toggle Latch, Stainless Steel, Compact Fastener
Made to Order
The NRH R5151-33 is a compact and lightweight toggle latch designed for reliable closure on small to medium-sized panels and enclosures. The product is constructed from Steel with Zinc Plating and finished with a Vibratory Finishing process. Key technical data confirms an ultra-lightweight design of 7g and a tensile load capacity of 78N (8kg). Its simple, over-center toggle mechanism provides a secure, tool-free latching solution for applications where space and weight are at a premium, offering a cost-effective fastening option.
Core Specifications (from product image & update):
-
Model: R5151-33
-
Material: Steel with Zinc Plating
-
Finish: Vibratory Finishing
-
Product Weight: 7g
-
Tensile Load: 78N (8kg)
-
Key Dimensions (from drawing): Length: 33.5mm; Width: 19mm; Height: 27.5mm; Material Thickness: 2mm; Mounting Holes: 4 x Ø3.2mm.
Product Overview: Compact and Reliable Latching
The R5151-33 operates on a straightforward toggle principle. The latch consists of a handle, a pivot, and a catch. In the open position, the handle stands upright. To close, the handle is pressed down, which causes the hooked catch to swing over and engage with a fixed strike plate or the edge of a panel. In the down position, the latch passes "over center," creating a mechanically locked state that resists vibration. To open, the handle is simply lifted. The use of Zinc Plating on steel provides a basic level of corrosion resistance and a clean finish, while the Vibratory Finishing ensures smooth operation and removes sharp edges, making it suitable for functional applications in controlled environments.
Technical Specifications & Core Features
-
Compact & Lightweight Design: With a minimal footprint (33.5mm L) and a weight of only 7g, this latch adds negligible bulk and mass, making it ideal for small equipment cases and electronic enclosures.
-
Reliable Toggle Mechanism: The over-center locking action provides a positive, vibration-resistant hold with a 78N tensile load capacity, securing panels effectively.
-
Cost-Effective Steel Construction: Made from Steel with Zinc Plating, it offers a good balance of strength and cost-effectiveness, providing basic rust protection for general-purpose use.
-
Smooth Finished Surface: The Vibratory Finishing process provides a uniform surface that is free of sharp edges, ensuring safe handling and a consistent appearance.
Ideal Applications
Given its small size, light weight, and dependable performance, the R5151-33 is well-suited for a variety of light-duty fastening needs in indoor or benign environments:
-
Small Instrument & Electronics Cases: Perfect for securing the lids of handheld test equipment, portable measurement devices, and sensor housings used indoors.
-
Control Panels & Access Covers: Used on small electrical control boxes, instrument panel covers, and inspection hatches on machinery in non-corrosive environments.
-
Network & Communication Devices: Suitable for securing covers on indoor modems, routers, switches, and other telecommunications equipment.
-
Lightweight Storage & Display Boxes: Ideal for presentation cases, sample boxes, or light-duty storage containers where a simple, secure closure is needed.
Choose a minimal and economical latching solution. The NRH R5151-33 Toggle Latch delivers reliable performance in a tiny package, combining the strength of steel with the basic protection of zinc plating for cost-conscious applications.
For further technical details or application support, please contact our team.
| Brand | NRH |
|---|---|
| Country of Origin | China |
| Certifications | CE, ISO9001, UL, SGS, RoHS |
| Minimum Order Quantity | 1 |
| Production Lead Time | 7-30 days |
| Stock Status | Made to Order |
