NRH 4201-110-1 Spring Handle | Chrome Plated SPCC Handle without Grip

The NRH 4201-110-1 is a cost-effective and functional spring handle designed for applications where a reliable carrying solution is needed without the requirement for a rubberized grip. Constructed from durable SPCC steel with a bright Chrome Plating finish, it provides essential functionality with a clean, all-metal aesthetic. This model features the same reliable spring mechanism with a 90-degree stop for stable lifting and automatic return action as other NRH handles, but is offered without a rubber or plastic grip overlay. With a net weight of 134g and a higher 294N (30kg) tensile load capacity, it is a robust choice for general industrial use.

Primary Applications

This no-frills, all-metal handle is suitable for a variety of standard applications:

Industrial Equipment & Consoles: Handles for control cabinets, server racks, electrical enclosures, and machinery housings where a metal finish is preferred.
Tool Storage & Workstations: Toolboxes, mobile carts, and workshop furniture that require a durable, easy-to-clean handle.
Transportation Cases: Flight cases, shipping containers, and composite boxes for equipment that does not require a cushioned grip.
Utility & Outdoor Enclosures: Generator covers, utility boxes, and outdoor equipment cases where environmental resistance is provided by the chrome plating.

How It Works (Operation Principle)

The handle operates on a straightforward spring mechanism. To use, pull the metal U-shaped bail upwards; it will extend until it reaches the integrated 90-degree stop, providing a stable position for carrying. To store, simply release the handle. The internal spring will automatically retract it, allowing the bail to fold down completely flat against the mounting plate. This offers a space-saving, low-profile design.

Features & Specifications

Pure Metal Construction: Made from SPCC steel with a Chrome Plating finish, offering a clean, industrial look without any rubber or plastic overlays.
90-Degree Carrying Stop: Provides a stable, fixed position for safe and easy lifting.
Automatic Spring Return: Retracts and folds flat automatically when released, maximizing space efficiency.
Higher Load Capacity: Rated for a tensile load of 294N (30kg), suitable for heavier applications.
Precise Dimensions: Engineered for easy installation with an overall length of 96mm, width of 71.5mm, and 4x Ø5.5mm mounting holes on a 61mm x 96mm pattern.

Technical Specifications

Item	Specification
Brand	NRH Box Hardware
Model Number	4201-110-1
Product Name	Spring Handle (No Grip)
Primary Material	SPCC Steel
Surface Finish	Chrome Plating
Grip	None (Bare Metal)
Product Weight	134g
Tensile Load	294N (30kg)
Key Dimensions	Overall Length: 96mm, Overall Width: 71.5mm, Bail Width: 30mm, Mounting Plate: 61mm x 96mm, Mounting Holes: 4 x Ø5.5mm.
Additional Details	Other dimensions as per drawing: 110, 84, 61, 2.2.
